Product name Cleancare
Materials grouping Gypsum




TVS Cleancare is manufactured according to the UNE-EN 14190 standard, based on a Type A laminated gypsum board covered with a white Polyvinyl Chloride (PVC) film that gives it special waterproofing and easy-cleaning qualities. Applications include removable ceilings in bathrooms, kitchens and areas where easy maintenance and cleaning are required.

It incorporates an aluminium-coloured sheet on its back-face that works as a vapour barrier and at the same time protects all the tile, in case of leaks or damage of the housing. It is a simple solution, of great quality and durability, packed in boxes of 8 units.

The tiles are available in white, black and smooth.

Technical Data

Edge: Square
Dimensions: White: 600 x 600mm / 600 x 1200mm, Black: 600 x 600mm, Smooth: 600 x 600mm
Thickness: 8.00mm (+/- 0.5mm)
Average Weight: 5.80kg/m2
Units/Box:
8 tiles (600 x 600mm) = 2.88m2 weight: 17kg per carton
6 tiles (600 x 1200mm) = 4.32m2 weight: 34kg per carton
Thermal Conductivity: 0.25 W/m K (UNE-EN 12524 Standard)
Fire Resistance (max.): 30 minutes
Coating Film: Polyvinyl chloride – 80g/m2


TVS Cleancare is manufactured according to the UNE-EN 14190 standard, based on a Type A laminated gypsum board covered with a white Polyvinyl Chloride (PVC) film that gives it special waterproofing and easy-cleaning qualities. Applications include removable ceilings in bathrooms, kitchens and areas where easy maintenance and cleaning are required.

It incorporates an aluminium-coloured sheet on its back-face that works as a vapour barrier and at the same time protects all the tile, in case of leaks or damage of the housing. It is a simple solution, of great quality and durability, packed in boxes of 8 units.

The tiles are available in white, black and smooth.

Technical Data

Edge: Square
Dimensions: White: 600 x 600mm / 600 x 1200mm, Black: 600 x 600mm, Smooth: 600 x 600mm
Thickness: 8.00mm (+/- 0.5mm)
Average Weight: 5.80kg/m2
Units/Box:
8 tiles (600 x 600mm) = 2.88m2 weight: 17kg per carton
6 tiles (600 x 1200mm) = 4.32m2 weight: 34kg per carton
Thermal Conductivity: 0.25 W/m K (UNE-EN 12524 Standard)
Fire Resistance (max.): 30 minutes
Coating Film: Polyvinyl chloride – 80g/m2





Downloads
  • TVS Cleancare ceiling tiles
    TVS Cleancare ceiling tiles
    2pp 395.45KB
    Download
