TVS Cleansound are speciality acoustic ceiling tiles for offices and public spaces that require high levels of acoustic absorption, whilst offering high resistance and an unalterable white colour. The combination of perforation and acoustic fleece provide great reverberation control.

It offers high acoustic performance, fire resistance and humidity resistance whilst having a minimal impact on the environment. Its aesthetic features are appreciated by architects and designers looking for a different appearance.

Technical data

  • Edge: square or tegular

  • Dimensions: 295 x 1195 / 595 x 595 / 595 x 1195mm

  • Thickness: 8 / 9.5 / 12.5mm (+/- 0.5mm)

  • Average weight: 5.8 / 6.55 / 9.1kg/m2

  • Units / box: 8 tiles = 2.88m2

  • Thermal conductivity: 0.25 W/m K (Norma UNE-EN 12524)

  • Fire reaction: A2 s1 d0 (Certification Nº EEA-1800-0071)

  • Fire resistance (max): 30 minutes

  • Coating film: polyvinyl chloride – white – 80g/m2

Advantages

  • High acoustic performance

  • Recyclable

  • Easy to clean

  • Durability and resistance

  • High light reflectance

  • High fire resistance

  • Moisture resistance

Suspended ceiling applications

  • Meeting rooms

  • Public spaces

  • Corridors

  • Offices

  • Theatres

  • Sound studios

  • Where high reverberation control is required.

Acoustic test information

The UNE-EN ISO 354: 2003 Standard that specifies the method to measure the acoustic absorption coefficient, was used to measure the absorption levels of TVS Cleansound ceilings.

  • Test board thickness: 12.5mm
    Approximate density: 730Kg/m3
    Plasterboard classification: NON-COMBUSTIBLE (A2 s1 d0)

  • Perforated surface: 16.6%
