TVS Cleancare ceiling tiles
TVS Cleancare ceiling tiles are manufactured according to the UNE-EN 14190 standard, based on a Type A laminated gypsum board covered with a white Polyvinyl Chloride (PVC) film that gives it special waterproofing and easy cleaning qualities. Applications include removable ceilings in bathrooms, kitchens and areas where easy maintenance and
TVS Cleancare ceiling tiles are manufactured according to the UNE-EN 14190 standard, based on a Type A laminated gypsum board covered with a white Polyvinyl Chloride (PVC) film that gives it special waterproofing and easy cleaning qualities.
Applications include removable ceilings in bathrooms, kitchens and areas where easy maintenance and cleaning are required.
Tiles incorporate an aluminium-coloured sheet on its back-face that works as a vapour barrier and at the same time protects all the tile, in case of leaks or damage of the housing. It is a simple solution, of great quality and durability, packed in boxes of 8 units.
Available in white, black and smooth.
Technical data
Edge: square
Dimensions: - white - 600 x 600mm / 600 x 1200mm - black - 600 x 600mm - smooth - 600 x 600mm
Thickness: 8.0mm (+/- 0.5mm)
Average weight: 5.80kg/m2
Units / box: - 8 tiles (600 x 600mm) = 2.88m2; weight - 17kg per carton - 6 tiles (600 x 1200mm) = 4.32m2; weight - 34kg per carton
Thermal conductivity: 0.25 W/m K (UNE-EN 12524 Standard)
